All-In-One Solar Streetlight F Series Of Outdoor Street Lamp

Description

Datesheet

Model	HS-SSL-F-40W	HS-SSL-F-60W	HS-SSL-F-80W	HS-SSL-F-100W	HS-SSL-F-120W	HS-SSL-F-150W
Solar Panel	50W/18V	80W/18V	100W/18V	110W/18V	120W/18V	150W/18V
Lithium Battery	192WH(3.2V)	288WH(3.2V)	400WH(3.2V)	480WH(3.2V)	640WH(3.2V)	768WH(3.2V)
CCT	2700-6500K
Lumen Efficiency	180LPW
Charging Time	5-6 hours
Working Time	12-15 hours (4 rainy days)
Control Mode	Time control + Microwave induction or Infrared induction
IP Rating	IP65
Mounting Height	4-6 meters	5-7 meters	6-8 meters	7-9 meters	8-10 meters	9-11 meters
Installing Space Between 2 Lamps	10-22 meters
Warranty	10 years
Lamp Lens	Glass lens

Product Parameters

Wattage	Prdoct Size(mm)	Carton Size(mm)
40W	885×385×95	945×442×180
60W	1075X385X95	1135×442×180
80W/100W	1325×385×95	1385×442×180
120W	1605×385×95	1665×442×180
150W	1605×455×95	1665×515×180

Alway Face Both Sun& Road

Recognizing the challenge where the ideal direction for street lighting does not always match the optimal orientation for solar panels, weíve engineered a solution with independently tiltable solar panels and LED modules. This innovative design ensures maximum solar energy capture and targeted area illumination, effectively addressing this common issue in solar street lighting.
